LG DualCool 2 Ton Inverter AC I27TCP

LG
Availability:

Out of stock


Shipping Time: 30 Days | Available on Pre-Order Only

  • Full DC Inverter AC
  • 65C Dual Inverter Compressor
  • T3 Compressor
  • 60% Faster Cooling
  • 65% Energy Saving
  • Comfort Sleep
  • Gold Fin

235,000.00

Out of stock

Brands:LG
Tropical Dual Inverter Compressor?
 Dual Inverter Compressor?1

Dual Inverter Compressor?

A compressor with a wider rotational frequency saves more energy and has a faster cooling range

10 Year Warranty1

10 Year Warranty

Verification obtained from TUV Rheinland for 10-year product life cycle

TUV Rheinland1

TUV Rheinland

TUV Rheinland, Verification on Fast Cooling & Power Saving Rate(aS-b246KcBd, BS-x186Kyb3)

4Way Swing1

4Way Swing

LG air conditioners deliver cool air to every corner of your room. The 4 way swing function blows the air quickly and efficiently in many direction.
Vertical 6 Steps Louver Control1

Vertical 6 Steps Louver Control

Users can choose the vane direction among 6 preset positions to meet the exact wind blow direction you desire.

Horizontal 5 steps Louver Control1

Horizontal 5 steps Louver Control

Direction of vertical louver can be adjusted from step 1 to 5, left & right, with full auto swing. This function also allows the air conditioner to cool specific areas in only a short period of time.

Comfort Sleep1

Comfort Sleep

Avail the utmost comfort sleep environment by automatically adjusting 3 different functions(Indirect airflow/7hr off time set/Soft wind & sleep time logic), with the simple click of button.

Gold Fin?1

Gold Fin?

The Gold Fin? ensures that the surface is more resistant to corrosion and enhances the durability of heat exchanger for a much longer period.

Auto Cleaning1

Auto Cleaning

It prevents forming of bacteria & mold on the heat exchanger. Thus provides a pleasant environment.

Dual Protection Filter1

Dual Protection Filter

The Dual Protection Filter captures dust size over 10? and bacteria.

Silent Mode1

Silent Mode

LG’s unique new skew fan & low vibration compressor technology achieve world’s lowest sound levels.

DIMENSIONS

CAPACITY

  • Cooling – Min ~ Rated ~ Max(kW)
    0.90/5.28/6.89
    Cooling – Min ~ Rated ~ Max(Btu/h)
    3,070/18,000/23,500
  • Cooling (T3) – Min ~ Rated ~ Max(kW)
    0.79/4.5/6.15
    Cooling (T3) – Min ~ Rated ~ Max(Btu/h)
    2,700/15,300/21,000

POWER INPUT

  • Cooling – Min ~ Rated ~ Max(W)
    320/1452/2900
    Cooling (T3) – Min ~ Rated ~ Max(W)
    374/1759/2900

RUNNING CURRENT

  • Cooling – Min ~ Rated ~ Max(A)
    1.45/6.5/14
    Cooling (T3) – Min ~ Rated ~ Max(A)
    1.77/7.8/14

EER

  • EER(W/W)
    3.64
    EER((Btu/h)/W)
    12.4

EER (T3)

  • EER (T3)(W/W)
    2.56
    EER (T3)((Btu/h)/W)
    8.7

ENERGY LABEL GRADE

  • Cooling / Heating
    4

POWER SUPPLY

  • Ø / V / Hz
    1 , 220 ~ 240 ,50

AVAILABLE VOLTAGE RANGE

  • Available Voltage Range(V)
    187 ~ 253

POWER FACTOR

  • Cooling / Heating(%)
    97.1 / –

MOISTURE REMOVAL

  • Moisture Removal(l/h)
    2.5

INDOOR

  • Air Flow Rate – Cooling, Max / H / M / L(㎥/min)
    19.0/14.5/13.0/10.5
    Sound Pressure Level – Cooling, Max / H / M / L / SL(dB(A))
    -/46/42/37/28
  • Dimensions (W × H × D) – Net(mm)
    998 x 345 x 210
    Dimensions (W × H × D) – Shipping(mm)
    1080 x 422 x 281
  • Weight – Net(kg)
    11.3
    Weight – Shipping(kg)
    13.4
  • Exterior Color Code
    Munsell 7.5BG 10/2 (RAL 9016)

OUTDOOR

  • Air Flow Rate – Max(㎥/min)
    49
    Sound Pressure Level – Cooling, Rated(dB(A))
    55
  • Dimensions (W × H × D) – Net(mm)
    870 x 650 x 330
    Dimensions (W × H × D) – Shipping(mm)
    1026 x 693 x 446
  • Weight – Net(kg)
    42
    Weight – Shipping(kg)
    46
  • Max. Fuse Size(A)
    25
    Exterior Color Code
    Munsell 9.54Y 8.34/1.31 (RAL 9001)
  • Operation Range – Cooling(℃ DB)
    18 ~ 54

CIRCUIT BREAKER

  • Circuit Breaker(A)
    25

POWER SUPPLY CABLE

  • Power Supply Cable(No. × ㎟)
    3 x 2.5

POWER SUPPLY TO UNIT

  • Power Supply to Unit
    Outdoor

POWER AND COMMUNICATION CABLE

  • Power and Communication Cable(No. × ㎟)
    4 x 0.75

PIPING

  • Size – Liquid(mm)
    Ø 6.35
    Size – Gas(mm)
    Ø 12.7
  • Connections Method – Indoor / Outdoor
    Flared / Flared

DRAIN HOSE SIZE

  • O.D, I.D(mm)
    21.5 , 16.0

BETWEEN INDOOR & OUTDOOR

  • Piping Length – Min / Standard / Max(m)
    3/5/30
    Piping Length – No Charge(m)
    7.5
  • Max. Elevation Difference(m)
    25
    Piping Connection Heat Insulation
    Both liquid and Gas Pipes

REFRIGERANT

  • Type
    R410A
    Pre Charge(g)
    1300
  • Additional Charge(g/m)
    15
    Control
    Electronics Expansion Valve

TOOL CODE (CHASSIS)

  • Indoor / Outdoor
    SK / U24A

COMPRESSOR

  • Type
    Dual Inverter Compressor
    Model
    GAT156MCA
  • Motor Type
    BLDC
    Oil Type / Maker
    POE (RB68A) / Sun Oil or Jx
    Nippon
  • Oil Charge (cc)
    400
    Manufacturer / Country of Origin
    LG Electronics/China

FAN(INDOOR)

  • Type
    Cross Flow Fan
    Motor Output(W)
    30

FAN(OUTDOOR)

  • Type
    Propeller Fan
    Motor Type
    BLDC
  • Motor Output (W)
    85
    Motor Insulation
    Class E
  • Motor Enclosure / Ingress Protection
    TEAO/IPX4

HEAT EXCHANGER

  • Evaporator – Material, Tube / Fin
    Cu/Al
    Evaporator – Corrosion Protection
    PCM
  • Condenser – Material, Tube / Fin
    Cu/Al
    Condenser – Corrosion Protection
    Gold
  • Condenser – Fin Type
    Louver
